Horizontal Pressure Booster Pumps


vanora pumps
vanora pumps

The Most Robust Pump Designed Ever For Water Pressure Boosting

It was once said that great things come in small packages. When you meet the Vanora booster pump for the first time. you'll certainly agree. This horizontal multi-stage pump has been created with compactness and modularity as two of its central features. Add reliability and quiet operation to the mix, and another innovative pump solution from Vanora is born.

Centrifugal modular. The pump is basically composed of a series of interchangeable modules, all of which have been designed to work together seamlessly, no matter the application.


Applications

Vanora pump with pressure controller is used for constant water pressure, can be ideal when space is constrained near the overhead tank.

Vanora pump is also supplied with pressure tank for constant water pressure, when the pressure drops to the pre-set level, the pump will start-up and when the water consumption drops again, the outlet pressure will rise to a pre-set stop pressure after which the pump will stop. Available from 2 Ltrs to 100 Ltrs tank range.


Features

  • Liquid temperature from 20 deg C upto 120 deg C
  • Built-in thermal protection
  • F class installation
  • 80 Start / Stop per hour

Construction

  • Electro-coated cast iron parts - free from corrosion
  • High efficient motor
  • Horizontal multistage centrifugal pump
  • Long life components are of corrosion and wear resistance stainless steel
  • SS304 Diffusers & Impellers
  • SS Shaft

Benefits

  • Highly Reliable
  • Compact Design and Silent Operation
  • Wide Performance Range

vanora pumps


horizontal openwell submersible plumps


vanora pumps
vanora pumps

  • Water lubricated carbon / thrust pad to with stand high axial load
  • High quality oil seal prevents the entry of foreign particles into the motor
  • Coated with ceramic epoxy paint to prevent corrosion
  • Ideally designed impeller dynamically balanced
  • Motor body & rotor shaft are made with stainless steel

Applications

  • Domestic water pumping to overhead tanks
  • Curing at construction sites
  • Fountains and gardening
  • Home pressure boosting systems
  • For agricultural use
  • For industrial use
  • Sprinkles and drip irrigation
  • Domestic use

Features

  • Highly rigid cast iron construction
  • Brass forged impeller
  • Graded steel shaft
  • Tested as per IS standards
  • Fitted with motor protector (T.O.P.)
  • Mechanical seal with high alumina seal face


vanora pumps

vanora pumps
Open well submersible pump
